IWISTAO HIFI Bluetooth 4.0 2X100W Power Amplifier NE5532 Preamp Transistor 2SA1941/ 2SC5198 APT-X

20 In stock

Bluetooth audio amplifiers

IWISTAO HIFI Bluetooth X100W Power Amplifier NE5532 Preamp 2SA1941 and 2SC5198 Power Stage Bluetooth 4.0 Transistor Amp APT-X   This is a HIFI Bluetooth Music Amplifier that adopts To shiba 2SA1941 and 2SC5198 transistor, and support Bluetooth 4.0, its output power is up to 2x100W. There is two modes of signal...
$199.00 $186.00
Save $13.00
Click to refer to Shipping Rate
+
-
$186.00
Wishlist

To add this product to your wish list you must Sign In or Create an account

IWISTAO HIFI Bluetooth X100W Power Amplifier NE5532 Preamp 2SA1941 and 2SC5198 Power Stage Bluetooth 4.0 Transistor Amp APT-X



This is a HIFI Bluetooth Music Amplifier that adopts To shiba 2SA1941 and 2SC5198 transistor, and support Bluetooth 4.0, its output power is up to 2x100W. There is two modes of signal input, Bluetooth and 3.5mm AUX line-on two modes, you can select by yourself.



IWISTAO HIFI 2x100W Bluetooth4.0 Power Amplifier Audio NE5532 Preamplifier 2SA1941/2SC5198 APT-X from IWISTAO HIFI MINIMART1 on Vimeo.







The HIFI Bluetooth music amplifier is designed as class AB with full structure of separated components and parts, and scientific, rational PCB layout and strict sound adjusted so that it performs distinctive sound. And add distortion servo circuit in the circuit design, so when large dynamic come, its performance is leisurely, unhurried. Meanwhile, its amplified circuit adopts NE5532 as a preamp, and T oshiba tube as power amplifier stage, these two parts complement each other. In addition, it builds amplifier speaker protection circuit inside to protect your speakers. Cooling system is made of blackening treatment process of heat sink, and a fan that connected with heat trace wire to the heat sink with forced cooling.



WBHF2100(b1l)





Brushed aluminum panels, black metal housing, it is noble and elegant. It is adopted that transformers toroidal with all copper, high efficiency and low leakage, which provides powerful current, thus providing better, more pure sound. As a HIFI Bluetooth desktop amp, front panel has a third selection for signal input, Bluetooth / PC / AUX; and there is tremble and bass knob for tone adjustment and AUX input jack.



Also there is bass and tremble adjustment knob on the front panel.

WBHF2100(bl)



Features

1.    PCB adopts double-sided design, so the amplifier is stable and reliable.

2.    Resistors with high precision metal film resistors, capacitors capacitance meter level precision.

3.    Filter capacitor with high-speed, low-loss high-capacity capacitor.

4.    Gold-plated RCA and terminal, so that the sound transmission is more smooth, pure.

5.    Setup bass and tremble adjustment knob on the front panel.



WBHF2100(Detail)WBHF2100(Detail2)



WBHF2100(b6L)

Diagram of Bluetooth Connection



WBHF2100(b4l)





Product Specifications

1.    Signal input: Bluetooth 4.0; 3.5mm AUX line-on.

2.    CSR8645 chip Bluetooth 4.0, support apt-x

3.    Amplifier Type: HIFI amplifier transistor.

4.    Output power: 2x 100W.

5.    Frequency Response: 30Hz ~ 20 KHz.

6.    THD : 0.01% (1kHz)

7.    SNR : >90dB

8.    Input Sensitivity : 450mv

9.    Output impedance : 4/8 ohm

10.    Color: Black

11. Size (W * D * H): 190mm * 310mm * 75m

12. Net weight : 3.5kg

13. Working voltage: 220~240V / 50 ~ 60Hz

14. Accessories

     Power cord x 1

    Anttena x 1



bt ant

15. Package: two High-strength corrugated boxes with full foam enclosure
