IWISTAO 2X200W HIFI Classic Class A ON MJL4281/4302 Discrete Component Stereo Power Amplifier Finished Board

298 In stock

Finished PCBA Amplifier Board

To add this product to your wish list you must Sign In or Create an account

IWISTAO 2X200W HIFI Classic Class A  ON MJL4281/4302 Discrete Component  Stereo Power Amplifier Finished Board Model No:WHFTA-CA688 This is a classic Class A power amplifier board with imported ON MJL 4281/4302. Beautiful timber, full vacuum tube taste, and has high power output, its maximum power is up to 2x200W.  ...
$199.00
+
-
$199.00
Important: Import duties, taxes and other customs related charges all are not included into shipping cost . Buyers bear all responsibility for all extra charges incurred (if any).

IWISTAO 2X200W HIFI Classic Class A  ON MJL4281/4302 Discrete Component  Stereo Power Amplifier Finished Board

Model No:WHFTA-CA688

This is a classic Class A power amplifier board with imported ON MJL 4281/4302. Beautiful timber, full vacuum tube taste, and has high power output, its maximum power is up to 2x200W.





WHFTA-CA688(2)WHFTA-CA688(2)1WHFTA-CA688(2)2WHFTA-CA688(2)3WHFTA-CA688(2)4

The input stage adopts American power differential transistors and medium power one for differential amplification to make its sound pure and soft. The output stage adopts 6 pairs of ON MJL4281/4302 power pair transistors, and 2 pcs high-precision temperature compensation one with constant current amplification designing, let its sound is more beautiful and delicate and sweet;

And, the protection circuit uses imported Omron relay; RC component uses high-precision fever components to ensure the consistency of the materials used in the whole unit.



Wire Connection

WHFTA-A686(1)l60

(Doesn't include the transformer and rectifier filter board, the photos only for you information)



Features

  1. Made with HIFI class components.
  2. Differential amplification input and constant current amplification technology ensure pure and soft sound.
  3. Equipped with high-power aluminum alloy fan and fan for heat dissipation, and convenient for fixed installation.
  4. Adopt 85 Celsius degree automatic overheat protection, double short circuit protection, and fan automatic shifting work.
  5. Equipped with speaker protection and delay protection circuit to protect valuable speakers.



Specifications

  1. Output power: 200W+200W
  2. Power amplifier board type: Class A
  3. Frequency response: 20Hz-180Khz
  4. Total harmonic distortion: < 0.01% (100W rms 4 ohms)
  5. Recommend power amplifier voltage: double DC positive and negative 40-86V
  6. Recomend protection power supply voltage: AC 12V-18V
  7. Matching speakers: 50-700W / 5 -15 inches speaker.
  8. Speaker impedance: 4-8 ohms
  9. Size (L*W*H): 200mm * 117mm* 82mm
  10. Weight: 3kg.
